525i59.94 NTSC, 625i50 PAL
Blackmagic mini convertor audio la SDI
Pret fara TVA:
4,041.67 MDL
Blackmagic mini convertor audio la SDI
4,850.00 MDL
4,850.00
Ai o intrebare?
Pentru embedare audio in orice sursa SDI, in formate SD si HD de pana la 1080p60. Semnalul audio este transmis ca analogic balansat sau AES/EBU folosind conectori de 1/4 inci de la echipamente precum mixere. Mini convertorul audio la SDI de la Blackmagic Design este ideal pentru embedare audio SD/HD SDI atunci cand un model Ultra HD nu isi justifica pretul.
|
Intrari video SDI
|
1 x SD, HD sau 3G‑SDI. 1 x ALT SDI pentru comutare automata daca feed-ul principal cade
|
|
Iesiri video SDI
|
1 x SDI embedat
|
|
Intrari audio analogice
|
4 canale de audio analogic balansat
|
|
Intrari audio digitale
|
8 canale de audio balansat AES/EBU
|
|
Formate
|
720p50, 720p59.94, 720p60, 1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30, 1080i50, 1080i59.94, 1080i60 2K DCI 23.98p, 2K DCI 24p, 2K DCI 25p, 2K DCI 23.98PsF, 2K DCI 24PsF, 2K DCI 25PsF SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M‑B, SMPTE 425M, ITU‑R BT.656, ITU‑R BT.601, SMPTE ST‑2036
|
|
Alimentare
|
+12V DC
|
| Dimensiuni | 115 x 92 x 23 mm |
